Ramp
(Ramp Up & Ramp Down)
e time required to reach the pulse width value and amplitude
setup value or from setup value to zero can be selected to be 1~8
seconds. (Ramp up value = Ramp down value).
Patient Compliance Timer
Operation count: record of 60 sets (min.), max with 999 mins.
Operation total time: max with 999 hrs.
Operation ambient:
Temperature range: 10°C ~ 35°C
Humidity range: 20 ~ 90%RH
Storage & transportation:
Temperature Range: 0°C ~ 70°C
Humidity Range: 20 ~ 90%RH
Timer: 5~90 minutes
auto-shuto or Constant
Size: L (120mm) x W (54mm) x H (33mm)
Weight 156 grams (including battery)
9.0 | TENS Stimulation Mode Descriptions
button. Be sure that when adjusting these stimulation modes, the intensity output controls should be set
to the minimum output first.
8.0 | Specifications continued
14
