EMSI FLEX-MT PLUS - Instructions For Use Continued; Connecting Electrodes and Lead Wires

19
Caution:
1. Always use 1 5” x 1.5” (16cm²) electrodes or larger.
3. Connect lead wires to unit:
Before proceeding to this step, be sure the unit is turned OFF.
Holding the insulated portion of the lead wire connector, insert the angled-“L” plug into the
receptacle on the top of the main unit. Please ensure the lead wires are inserted securely.
Control buttons on the front of the unit. You may choose to use one channel with one pair of lead
wires or both channels with two pairs of lead wires.
Caution: Always use leadwires that came with the unit. Using other leadwires may render
the unit non-operable and void the warranty.
2. e Flex-MT® Plus is compatible and recommended for use with EMSI electrodes
(or comparable). Always use electrodes and leadwires that came with the unit. Using other
electrodes and leadwires may render the unit non-operable, ineective, and void the warranty.
CONNECTING THE STIMULATOR
2. Connect electrodes to lead wires:
Insert the lead wire connector into electrodes connector (standard 0.08 inch female connection).
MAKE SURE THAT NO BARE METAL OF THE PINS IS EXPOSED
