4.2.2 MATERIAL
It’s the operator’s responsibility to chose the correct material according to the individual setup and all
relevant local safety guidelines, rules, directives and regulations.
 L-pieces, I-pieces and T-pieces for the LLDPE and stainless steel pipes
 H
2
O IN:
o Push-fit locking clips for 10 mm pipes (to fix the pipes within the connectors)
o 10 mm diameter LLDPE tubing (ensure the tubing is pressure-resistant to at least 4 bar!)
 H
2
OUT/VENT:
o ¼” stainless steel tube fitting male ISO parallel thread connectors
o Stainless steel pipes AISI 316L - ASTM A269 with at least ¼” outside diameter or equivalent
material in terms of tightness, resistance to corrosion, hydrogen embrittlement, fire
conditions and the required pressures of at least 45 barg
 O
2
VENT:
o ⅜” stainless steel tube fitting male ISO parallel thread connector
o Stainless steel pipes AISI 316L - ASTM A269 with at least ⅜” outside diameter or equivalent
material in terms of tightness, resistance to corrosion and temperature, and fire conditions
4.2.3 ACCESSORIES (INCLUDED IN THE BOX)
 Electrolyte filling bag with pipe and connectors (labelled)
 DRY CON jumpers
 Ferrite cylinder for the Dry Contact output cable
