Attention!
Double-check all the wiring connections before supplying power to the device. Failure
to adhere to the following instructions can damage the device and lead to hazardous
conditions in and around the device!
Never handle the electrical connections with wet hands!
Follow the relevant safety standards and ensure compliance with all relevant local safety guidelines,
rules, directives and regulations. Ensure that the connectors is used in the correct orientation, as shown
in the picture. Do not exceed the specified voltage and amperage (see datasheet for more details).
Enapter recommends installing a protective device against overload and short circuits for all device
versions on the power supply line. It must be selected in relation to the devices maximum power
consumption and in compliance with all local and national safety requirements. To further increase
electrical safety of the device, it is recommended to install an SPD (Surge Protection Device) to protect
the device from potential over-voltages generated by lightning strikes, as well as an appropriately sized
differential breaker for the installation.
4.7.1 AC VERSION
Connect the device to the socket labelled “Power”. Brown is live, blue is neutral, and yellow/green is
the protective earth connection. The AC version of the device has fuses on the front panel which can
be replaced in case they burned.
