ASSEMBLY INSTRUCTIONS EC18017 / EC18018
7
STEP 3.3
1
1. Insert (1) Spacer (H) into each post as shown below. Slide the spacer until it
hits the installed rail.
2. Insert (1) Narrow Board (D) into the post channels until it hits the spacers.
STEP 3.4
2
D
E
H
Follow the same process in STEP 3.3 with (5) additional narrow boards and (2) Wide Boards (E) in the
pattern shown below. Ensure there is a spacer between each board.
