ENHWI-3GN3 User’s Manual
www.encore-usa.com
69
Enable Trigger Port: Enable or disable the Port Trigger function.
Trigger Port: This is the outgoing (Outbound) range of port numbers for this
particular application.
Trigger Type: Select whether the outbound port protocol is “TCP”, “UDP” or
“BOTH”.
Public Port: Enter the In-coming (Inbound) port or port range for this type of
application (e.g. 2300-2400, 47624)
Public Type: Select the Inbound port protocol type: “TCP”, “UDP” or “BOTH”
Popular Applications: This section lists the more popular applications that
require multiple connections. Select an application
from the Popular Applications selection. Once you
have selected an application, select a location (1-5) in
the “Add” selection box and then click the <Add>
button. This will automatically list the Public Ports
required for this popular application in the location (1-
5) you specified.
Add Port Triggering
Fill in the "Trigger Port", "Trigger Type”, “Public Port”, "Public Type",
"Public Port" and "Description" of the setting to be added and then Click
<Add>. The Port Triggering setting will be added into the "Current Trigger-
Port Table" below. If you happen to make a mistake, just click <Reset>
and the fields will be cleared.
Remove Port Triggering
If you want to remove Special Application settings from the "Current Trigger-
Port Table", select the Port Triggering settings you want to remove in the table
and then click <Delete Selected>. If you want remove all Port Triggering settings
from the table, just click the <Delete All> button. Click <Reset> will clear your
current selections.
