ENHWI-3GN3 User’s Manual
www.encore-usa.com
7
Item Description
Reset
Press and release this button to reboot the device. Press
and hold this button for 10 seconds to load the factory
default settings of the system.
WPS Button Push-n-Connect
Press this button to start Push-n-Connect (WPS)
function.
DC 12V
Power connector, connects to a DC 12V 1A Power
Adapter (Supplied)
LAN1 and LAN2
Ports 1 and 2 Local Area Network (LAN) 10/100 Mbps
RJ-45 ports
USB Port
Used for 3G USB Modem (Not included) from your 3G
ISP subscription
WAN
Wide Area Network (WAN) port or
Internet Port. Connects to xDSL or Cable Modem
2. Installation
2.1- NETWORK PLUS SYSTEM REQUIREMENTS
To begin using the ENHWI-3GN3, make sure you meet the following as minimum requirements:
h PC / Notebook Computer as client
h Operating System – Microsoft™
Windows
®
98SE/ME/XP/2000/ Windows Vista™ /
Windows
®
7
h Computer with 1 working RJ-45 Network Interface Card port
h Wi-Fi adapter card – (optional for Wireless LAN installation procedure)
h Internet connection (Subscription to your local ISP may be required)
o External xDSL (ADSL) or Cable modem internet subscription with an Ethernet
WAN port (RJ-45) or
o 3G USB Modem for Internet Connection
h A Web Browser running Internet Explorer, Safari, Firefox, Opera etc.
h Ethernet compatible CAT5 or better cables.
