2-2 WAN
The Broadband Router can be connected to the service provider in any of
the following ways: Dynamic IP Address, Static IP Address, PPPoE and
PPTP.
2-2-1 Dynamic IP
The Host Name is optional, but may be required by some Service
Providers. The default MAC address is set to the WAN's physical
interface on the Broadband Router. If the Service Provider requires the
host name, using the "Clone MAC Address" button to copy the MAC
address of the Network Interface Card installed in the selected PC and
replaces the WAN MAC address with this MAC address.
The road runner management is optional. If the ISP needs to run the road
runner management (sometimes called Big Pond), enable it.
2-2-2 Static IP
If the Service Provider has
assigned a fixed IP address,
enter the assigned IP
address subnet mask and
gateway address provided.
Click “yes” if using two or
more IP addresses.
25
