(the amount is shown with brightness of the
red
LED), which is useful to
enhance the delays or for dub-delays.
9. TIME/DIV KNOB with LED:
controls the delay time, from short
audio rate repeats CCW and longer taps CW as a primary parameter (the
amount is shown with the brightness of the
blue
LED). Secondary
/MIDI
CLOCK*
function (pressing or holding
SHIFT
while turning the knob from
noon CW) enables the delay to be synchronized to an external MIDI clock
received at the
MIDI IN
connector (5). While the external clock is enabled,
TIME/
DIV
knob acts as a divider / multiplier for the clock with the dividers
written around the knob on the panel and LED flashes
red
according to the
external clock speed.
10. REPEATS
/TAPS*
KNOB with LED:
controls the
REPEATS
or
FEEDBACK
level of the delay (this amount is shown with the brightness of
the
blue
LED). Turn it fully CW for self-oscillation. Secondary
/TAPS*
function
(pressing or holding
SHIFT
while turning the knob in 3 sectors from CCW to
11 o’clock, 11 to 14 o’clock and 14 to full CW shown with brightness of the
red
LED) changes the stereo behavior of the taps produced by the delay (see
DELAY section below).
11. REVERB KNOB with LED:
controls the
REVERB DRY/WET MIX
level (that amount is shown with the brightness of the
blue
LED). Secondary
/TONE*
function (pressing or holding
SHIFT
while turning that knob) adjusts
the tilt EQ before the reverb tank (the amount is shown with the brightness of
the
red
LED) which is useful to get rid of the boomy low-end
12. DECAY
/PREDELAY*
KNOB with LED:
primary function controls
the decay of the
REVERB’s TAIL
(that amount is shown with the brightness of
the
blue
LED). Secondary function in combination with the
SHIFT
button
controls the
AMOUNT OF PRE-DELAY
- time of the beginning of the first
reflections of the reverb (the amount is shown with the brightness of the
red
LED). Amount of pre-delay may be perceived as the apparent size of our
‘space’.
13. REVERB TYPE /
/FILTER*
BUTTON:
primary function selects the
reverb algorithm between: hall with shimmer, reverse and spring reverbs.
Secondary function in combination with the
SHIFT
button switches the filter
algorithms: bipolar SVF LP/HP, BANDPASS or COMB filter. Selected reverb
and filter types shown with the columns of LEDs.
14. TAP
/ASSIGN*
FOOTSWITCH with LED:
multi-function foot
switch, can be assigned to various controls via
SHIFT+TAP
combination. By
default assigned to the TAP tempo of the DELAY and
white
TAP LED blinks
according to the delay clock. For more details on modes see the
TAP
FOOTSWITCH ASSIGNMENT
section below.
