Endress+Hauser Levelflex M FMP41C Technical Information

Levelflex M FMP40
6 Endress+Hauser
Measuring system Probe selection
The various types of probe in combination with the process connections are suitable for the following
applications:
Probes with 1½" threaded connection or flange
Type of probe: 6 mm rope probe 6 mm rope probe
PA-coated
1)
4mm rope probe 16 mm rod robe 16 mm rod probe,
separable probe
Coax probe
Max. probe length: 35 m
2)
35 m
2)
Liquids: 35 m
Bulk solids: 15 m
4m 10 m 4m
For application: • Bulk solids • Bulk solids
especially cereal,
flour
•Liquids
measuring range
> 4 m
•Liquids
• bulk solids on
short measuring
ranges and
sideway
mounting
•Interface
measurement
•Liquids
• cramped mounting
position (limited
head clearance)
• Interface
measurement
•Liquids
• Interface
measurement
Sideways capacity: not relevant not relevant not relevant 30 Nm 20 Nm 300 Nm
Tensile loading capacity
(min.):
rupture load (max.):
3)
30 kN
35 kN
30 kN
35 kN
12 kN
16 kN
not relevant not relevant not relevant
Feature 30 Option "B" Option "H" Option "A" Option "K" Option "S, T, U, V" Option "L"
1) ø6 mm + 2 mm PA coating.
2) Greater lengths available on request.
3) Max. load of silo ceiling. If overloaded, the rope tears; the bushing remains air-tight.
