Levelflex M FMP40
Endress+Hauser 7
Probes with ¾" threaded connection
Stand-alone
• Power supply directly from power line (4-wire) or from transmitter power supply unit (2-wire).
• Onsite operation with integrated display or remote operation with HART protocol.
L00-FMxxxxxx-14-00-06-en-008
Type of probe: 4 mm rope probe 6 mm rod probe Coax probe
Max. probe length: 35 m
1)
1) Greater lengths available on request.
2m 4m
For application: •Liquids
measuring range > 4 m
•Liquids
• Interface measurement
•Liquids
• Interface measurement
Sideways capacity: not relevant 4 Nm 60 Nm
Tensile loading capacity (min.):
rupture load (max.):
2)
2) Max. load of silo ceiling. If overloaded, the rope tears; the bushing remains air-tight.
5 kN
12 kN
not relevant not relevant
Feature 30 Option "A" Option "P" Option "L"
