Levelflex M FMP40
8 Endress+Hauser
System integration via PROFIBUS PA
Maximum 32 transmitters (depending on the segment coupler, 10 in the Ex ia IIC hazardous area according
to the FISCO Model) can be connected to the bus. The Bus voltage is supplied by the segment coupler.
Both onsite as well as remote operation are possible.
L00-FMxxxxxx-14-00-06-en-001
System integration via FOUNDATION Fieldbus
Max. 32 transmitters (standard, Ex em or Ex d) can be connected to the bus. In Ex ia IIC explosion protection:
the max. number of transmitters is based on the applicable regulations and standards for interconnecting
intrinsically safe circuits (EN 60079-14, proof of intrinsic safety). Both onsite as well as remote operation are
possible. The complete measuring system consists of:
L00-FMxxxxxx-14-00-06-en-003
