Step 6 Step 6
A. Connect Bracket Cover (30) to Right Stride Adjustment Frame (S)
using:
One 66 (M5x12 phillips head pan screw)
NOTE: Do not overtighten screw, this will damage Bracket Cover (30).
B. Connect Bracket Cover (30) to Left Stride Adjustment Frame (J)
using:
One 66 (M5x12 phillips head pan screw)
NOTE: Do not overtighten screw, this will damage Bracket Cover (30).
16
