Battery Charger RLD
User's Manual
• MANUAL CHARGE TERMINATION:
The charge can be manually terminated in any moment, by pressing the red STOP pushbutton.
The display will show the message “Stop”:
At this point, it's possible to disconnect the battery.
EQUALIZATION
The EQUALIZATION function is useful to keep all the cells of the battery at the same voltage
level, even after years of continuous work. When a battery is charged/discharged everyday, it's
suggested to equalize it weekly.
The charger, after a normally completed charge cycle, will add 4 extra charges of 30 minutes,
with 15 hours interval between each charge.
During the interval between each equalization charge, the display will show the scrolling
message: “End”:
When the equalization chargers are in progress, the display will show the message“F1”,
followed by the current value:
OWM-AR-D-[] Page 20 of 23
NOTES
After the charge termination, while the battery remains connected, the final values of
[Voltage/cell], [Time] and [Capacity charged] remain stored in memory.
If the red STOP pushbutton is pressed, the display will show these values in sequence.
If the charge has been terminated manually, equalization and
maintenance functions are automatically disabled.
