Battery Charger RX
User's Manual
START OF THE CHARGE
The charger can be turned on only when the battery is correctly connected.
The charge can start in two ways, depending by the position of the main switch .
(When the charge is complete, the user may disconnect the battery from the charger to start
working, without turning the main switch to position “0”. This is not a problem, because the
charger, when the battery is re-connected, will start the charge after a few seconds, to avoid
sparks between contactors ).
If the main switch is set on “0”, when the battery is connected the LEDs on the control panel flash
alternately.
Now, to start the charge, it’s necessary to set the main switch to position “1”.
If the main switch is already in position “1”, the charge starts after about 5 seconds of delay.
When the charge is started, the second LED “CHARGE ON” will flash at frequency of about 1 second.
CHARGE OPERATIONS
OWM-040906-RX Version: 02-AB Page 12 of 25
WARNING !
When the charge is started, check that the LED “CHARGE ON” is flashing at
frequency of about 1 second. This control is useful to be sure that the electronic
control is working correctly.
WARNING !
ENERGIC Plus RX chargers are programmed to do a complete cycle of charge,
however it’s recommended to survey the operations when the battery must remain
connected to the charger for more than 12 hours (example: week-ends)
NOTE
The operations described in this chapter are done by
ENERGIC Plus RX chargers automatically.
