Energic Plus RX - Spare Parts List

Battery Charger RX
User's Manual
SPARE PARTS LIST
COMMON PARTS – SINGLEPHASE CABINET S
POSITION CODE DESCRIPTION
1-S 0203340 Base RE box S
2-S 0203341 Cover RE box S
3-S 0203129T Printcard external plate RX
4-S RLCBSRE-06-01 Printcard support (x4)
5-S 0201321 Main switch 0-1
6-S 0201829 Cable strain relief
7-S 0201828 Cable strain relief
8-S 0100999 Hand grip
9-S 100001 Output fuse holder
10-S 1011CA01 Plastic feet RE (x4)
VARIABLE PARTS – SINGLEPHASE CABINET S
POS. DESCR. 12-25 24-20 24-25 24-30
11-S
Rectifier
0201911 0201903 0202032 0202032
12-S
Printcard 567SCE
0302761 0302762 0302762 0302762
13-S
Output fuse
0201062 0201062 0201062 0201062
COMMON PARTS – SINGLEPHASE CABINET A
POSITION CODE DESCRIPTION
1-A 0203345 Base RE box A
2-A 0203346 Cover RE box A
3-A 0203129T Printcard external plate RX
4-A RLCBSRE-06-01 Printcard support (x4)
5-A 0201321 Main switch 0-1
6-A 100001 Output fuse holder
7-A 1011CA01 Plastic feet RE (x4)
VARIABLE PARTS – SINGLEPHASE CABINET A
POS. DESCR. 24-40 24-50 24-60
8-A Rectifier 0202033 0201914 0202016
9-A Printcard 567SCE 0302762 0302762 0302762
10-A Output fuse 0201063 0201064 0201065
COMMON PARTS – SINGLEPHASE CABINET B
POSITION CODE DESCRIPTION
1-B 0203370 Base RE box B
2-B 0203374 Cover RE box B
3-B 0203129T Printcard external plate RX
4-B RLCBSRE-06-01 Printcard support (x4)
5-B 0201321 Main switch 0-1
6-B 100001 Output fuse holder
7-B 1020CA01 Plastic feet RE (x4)
VARIABLE PARTS – SINGLEPHASE CABINET B
POS DESCR. 48-60 48-80
8-B Rectifier 0202016 0202017
9-B Printcard 567SCE 0302764 0302764
10-B Output fuse 0201065 0201066
OWM-040906-RX Version: 02-AB Page 24 of 25
