Energomera CE102 - 2.1.9 Meter Model Variations

6 7
2.1.9 Meter modifications
Meters modifications are specified by designation structure, given in the Figure 2.1.
СЕ 102 R5.1 145 JАN
Interfaces and additional options:
N – Interface external supply
А – EIA-485
J – optical port
Base (max.) current:
5 – 5 (60)
Nominal voltage:
4 – 230 V
Accuracy class according to IEC 62053-21:2003:
1 – 1
Case type:
R5.1 – for Din-rail mounting
Figure 2.1 – Designation structure
