Table 2.3
Specification name Specification value Note
Nominal (max.) currents 5(10) А Transformer connection
Base (max.) currents 5(60); 5(100) Direct connection
Nominal phase voltage
57.7 V; 230 V Transformer connection
230 V Direct connection
Operating phase voltage (0.6 (0.75)*...1.21) U
nom
V
* — for meters with 57.7 V
nominal voltage
Nominal network frequency (50±2.5) Hz
Non-sinusoidal factor of the measuring
network voltage, %, max
– In accordance with EN50160:2010
Sensitivity threshold
Direct
connection
Transformer
connection
Active/reactive energy
– 0.001 I
nom
A 0.2S/0.5; 0.5S/0.5
0.002 I
b
A
1/1
Number of decimal places on the LCD from Table 2.2
Total power consumed by each current
circuit, max
0.1 (V•A) With nominal (base) current
