18
Specification name Specification value Note
Meter update time 1 s
Initial start, max 5 s
From the moment the voltage is
applied
Meter weight, max 3 kg for CE308 S31, S34
Overall dimensions (height; width;
length), max, mm
72х175х215 for CE308 S31
85х175х280 for CE308 S34
Mean time to failure 220,000 h
Average service life 30 years
Meter cover and terminal block cover
opening control
Meter cover and terminal
cover opening logs
Protection against unauthorized access
Meter password, hardware
lock
Maximum current at the relay contacts
during the turn-off (turn-on) opera-
tion, does not exceed
1.1 Imax А
Permissible switching voltage on the
alarm relay contacts, max
265 V AC; 30 V DC in the
S version
Table 2.3 (continued)
