Enerpac SHS - 5. Product Technical Data; 5.3 Manual SHS Pump Capabilities

10
L4627_b
5. Product Technical Data
5.1 Manual SHS Pumps Dimensional Callout Art
Figure 7: Manual SHS pump dimensions
5.2 Manual SHS Pumps Dimensional Table
Measurement
SHP414MW / SHP414MJ
SHP421MW / SHP421MJ
mm in
A 1418 55.82
B 832 32.75
C 1090 42.91
5.3 Manual SHS Pump Capabilities
SHP414MW SHP414MJ SHS421MW SHP421MJ
Flow
4 x 1.4
l/min
4 x 0.36
gal/min
4 x 1.68
l/min
4 x 0.44
gal/min
4 x 2.1
l/min
4 x 0.55
gal/min
4 x 2.52
l/min
4 x 0.66
gal/min
Max. Pressure 700 bar 10150 psi 700 bar 10150 psi 700 bar 10150 psi 700 bar 10150 psi
Reservoir 250 l 66.04 gal 250 l 66.04 gal 250 l 66.04 gal 250 l 66.04 gal
Wet Weight 695 kg 1532.21 lbs 695 kg 1532.21 lbs 725 kg 1598.35 lbs 725 kg 1598.35 lbs
Motor Power 7.5 kW 9 kW 11kW 13.2 kW
Motor Speed 1500 RPM 1800 RPM 1500 RPM 1800 RPM
Frequency 50 Hz 60 Hz 50 Hz 60 Hz
Power Supply 400 V 480 V 400 V 480 V
Oil Grade HF95 (Enerpac)



