5.6 SHS Cylinders Capabilities
Technical specifications of these cylinders in the
following tables:
• For 55 Ton Cylinders: SHC5520, SHC5540, and
SHC5560.
55 Ton Cylinder Characteristics
Pushing Pressure 125 bar 1812 psi
Pushing Capacity 18.2 Ton 178.48 kN
Pulling Pressure 700 Bar 10150 psi
Pulling Capacity 56.78 Ton 556.82 kN
External Diameter 245 mm 9.64 in
Internal Diameter 135 mm 5.31 in
Plunger Diameter 90 mm 3.54 in
Effec. Area (Pushing) 143.1 cm
2
22.18 in
2
Effec. Area (Pulling) 79.5 cm
2
12.32 in
2
Area Ratio 1.80
Model SHC5520 SHC5540 SHC5560
Oil Capacity
(Pushing)
7.16 L 14.3 L 21.5 L
1.89 gal 3.77 gal 5.67 gal
Oil Capacity
(Pulling)
3.98 L 7.9 L 11.9 L
1.05 gal 2.08 gal 3.14
Stroke
500 mm 1000 mm 1500 mm
19.68 in 39.37 in 59.05 in
Weight
476 kg 624 kg 800 kg
1049.4 lbs 1375.68 lbs 1763.7 lbs
• For 85 Ton Cylinders: SHC8520, SHC8540 and
SHC8560.
85 Ton Cylinder Characteristics
Pushing Pressure 125 bar 1,812 psi
Pushing Capacity 25.6 Ton 251.05
Pulling Pressure 700 bar 10150 psi
Pulling Capacity 87.5 Ton 858.08 kN
External Diameter 265 mm 10.43 in
Internal Diameter 160 mm 6.29 in
Plunger Diameter 100 mm 3.93 in
Effec. Area (Pushing) 201.1 cm
2
31.17 in
2
Effec. Area (Pulling) 122.5 cm
2
18.98 in
2
Area Ratio 1.64
Model SHC8520 SHC8540 SHC8560
Oil Capacity
(Pushing)
10.05 L 20.11 L 30.16 L
2.65 gal 5.31 gal 7.96 gal
Oil Capacity
(Pulling)
6.13 L 12.25 L 18.38 L
1.61 gal 3.23 gal 4.85 gal
Stroke
500 mm 1000 mm 1500 mm
19.68 in 39.37 in 59.05 in
Weight
531 kg 700 kg 900 kg
1170.65 lbs 1543.24 lbs 1984.16 lbs
• For 110 Ton Cylinders: SHC11020, SHC11040 and
SHC11060.
110 Ton Cylinder Characteristics
Pushing Pressure 125 bar 1812 psi
Pushing Capacity 36.1 Ton 354.02 kN
Pulling Pressure 700 bar 10150 psi
Pulling Capacity 114.8 Ton 1125.8 kN
External Diameter 315 mm 12.40 in
Internal Diameter 190 mm 7.48 in
Plunger Diameter 125 mm 4.92 in
Effec Area (Pushing) 283.5 cm
2
439.42 in
2
Effec Area (Pulling) 160.8 cm
2
249.24 in
2
Area Ratio 1.76
Model SHC11020 SHC11040 SHC11060
Oil Capacity
(Pushing)
14.18 L 28.35 L 42.53 L
3.74 gal 7.48 gal 11.23 gal
Oil Capacity
(Pulling)
8.04 L 16.08 L 24.12 L
2.12 gal 4.24 gal 6.37 gal
Stroke
500 mm 1000 mm 1500 mm
19.68 in 39.37 in 59.05 in
Weight
750 kg 970 kg 1235 kg
1653.47 lbs 2138.48 lbs 2722.70 lbs
5.7 SHS Description
Enerpac SyncHoist System is a unique crane product
for below-the-hook heavy load positioning that require
precision placement.
Manual SHS is composed of 4 specialized hydraulic
cylinders which have an internally mounted distribution
block. These cylinders are connected to an included
powerpack or HPU which provides the operator
freedom to precisely monitor and adjust each lifting
point independently.
Manual HPU has 4 levers to control cylinder movements
with an optional pressure reading screen to easy monitor
the pressure going on each line.
The system is designed for 10150 psi [700 bar] maximum
working pressure.
5.8 Product Table
There can be several configurations of this system
depending on the HPU and cylinder model used. HPUs
can be W model, with a 400 V, 3ph, 50Hz powerpack, and
J model, with a 480V, 3ph, 60Hz powerpack. Cylinders
have 3 different models, which are normal ones with
no sensors, P models with pressure transducers, and
S models, which incorporates pressure transducers
and stroke sensor. All different combinations can be
checked on the following table.
