4. Secure all connections finger-tight to allow for some adjustment of position.
5. After all connections are completed, torque all stainless steel connector bolts according
to Table 7.1.
TABLE 7.1
316SS Bolt Size
Diameter -
Threads/Inch
Initial Torque Value
Inch-Pounds
(Newton Meter)
Retorque Value
Inch-Pounds
(Newton Meter)
1/4 - 20 70 – 75
(8.0 - 8.5)
60 – 65
(7.0 - 7.5)
5/16 - 18 120 – 125
(13.6 - 14.1)
110 – 115
(12.5 - 13.0)
1/2 - 13 130 – 135
(14.7 - 15.3)
120 – 125
(13.6 - 14.1)
Make sure that all bolted battery connections are torqued to
the recommended values. The increased resistance of a loose
connection can generate heat and become a fire hazard.
6. Apply a light coat of heated NO-OX-ID grease to the bolted connection with a small
paintbrush in the area of the terminal post only.
