ENERVEX Multiple Fireplace - Page 5

5
3940011 12.12
2.1 EBC 30 Control
EBC 30 Control
Power Supply V
1x120VAC
Amperage A
6.3
Operating Temperature °F / °C
-4 to 122/-20 to 50
Range of Operation inWC / Pa
0-0.6 / 0-150
Tolerance inWC / Pa
0.01/3 +/-10%
Control Signal mA
max. 10
Control Relay
Max. 120 VAC/8A
Output VAC
10-120
VDC
0-10
Dimensions A in / mm
14.65 / 372
B in / mm
11.03 / 280
C in / mm
4.22 / 107
Weight lbs / kg
8.9 / 4.0
EMC Standard Emission
EN 50 081-1
Immunity
EN 50 082-2
2. DIMENSIONS & CAPACITIES
