ENERVEX Multiple Fireplace - XTP2 Sensor; Stack Probe

7
3940011 12.12
XTP2 Sensor
Power Supply VDC 12-36
Amperage mA <20
Output VDC 0-10
Operating Temperature °F/°C 0 to 160 / -18 to 71
Accuracy inWC/Pa +/- 0.08%
Dimensions D in/mm 3.70 / 94
E in/mm 5.12 / 130
F in/mm 6.18 / 157
G in/mm 3.13 / 80
Weight lbs/kg .6/.3
2.3 XTP Sensor
2.4 Stack Probe
Stack Probe
Dimensions H in / mm 4.25 / 108
I in / mm 3.50 / 89
