Figure: 15 - Internal SIM Holder
3.4 Power
The Enfora MT 3000 device draws 9-16 Vdc (SAE J1211 compliant) power from the vehicle's OBDII port. No
additional power cabling is required.
3.5 Micro USB
Warning: The Micro USB (2.0) connector is an input/output connector and is not
intended for general use. This connector should only be used when programming the
modem.
Note: This USB port cannot be used to supply power to other USB devices and nothing
should be connected to this port when the vehicle is in motion. The MT3000 can not
be powered through the USBPort.
The micro USB connector is only used to program the modem. When programming the modem, a micro
USB cable is required.
