Engbo MAXI 34-series User Manual (English)

Questions and Answers:

T
Tyrone LambertAug 8, 2025
What to do if Engbo Boating Equipment windlass does not work or pulls very poorly?
- A
  Andrea StewartAug 8, 2025
  If your Engbo boating equipment windlass isn't working well, start by checking the main power supply. Measure the voltage in the battery cables at the point where they connect to the windlass while it's running. If the voltage is less than 10.5V, investigate the cause. Inspect all connection points, including the main switch, fuse, battery shoes, and the battery's overall condition and voltage. If the voltage is above 10.5V but the motor still doesn't work, the electronic protection function might have shut it down due to prolonged use or overload. Let it cool down for about 20 minutes before trying again.
L
Luis JonesAug 15, 2025
How to troubleshoot Engbo MAXI 34 Boating Equipment if the windlass is completely dead?
- B
  Beth BerryAug 15, 2025
  If your Engbo boating equipment windlass is completely dead, begin by verifying that the main switch is in the ON position and the fuse is intact. Ensure all connection points are making proper contact and that all connections align with the diagrams provided in the manual. Finally, confirm that there's sufficient voltage being supplied to the windlass motor.
C
Cody LiAug 23, 2025
Why Engbo MAXI 34 Boating Equipment windlass will not drop anchor and only winds in for 3 s?
- B
  Brent JonesAug 23, 2025
  If your Engbo boating equipment windlass only winds in for 3 seconds and refuses to drop anchor, check that the connections to the electronic control unit (1, 2, and 3) match the diagram. Try swapping connections 1 and 3; this should restore correct function.
J
James GreeneAug 30, 2025
What to check if auto stop function does not work on Engbo MAXI 34?
- W
  watersshawnaAug 30, 2025
  If the auto stop function isn't working on your Engbo boating equipment, specifically on rope windlasses, start by checking the following: - Ensure the connections to points 4, 5, and 6 are correctly configured according to the diagram. - Verify that the voltage to the emitter (between points 4 and 6) exceeds 10 V DC. - Confirm that the auto stop wires are properly positioned. - Check that the auto stop emitter is at the correct distance from the rope. If the voltage is adequate and the emitter distance is correct, but the lamp remains unlit, the emitter likely needs replacement.

Engbo MAXI 34-series Specifications

General

Model	MAXI 34-series
Category	Boating Equipment
Type	Windlass
Voltage	12V / 24V
Max. Chain Size	10 mm
Max. Rope Size	14 mm
Motor Power	1000 W
Material	Stainless Steel
Battery Compatibility	12V
Control	Remote

Summary

Introduction

General procedures for using Engbo Maxi windlasses

Operating instructions

Preparation before anchoring

Steps to take before starting the anchoring process.

Landing

Procedure for dropping the anchor and securing the boat on land.

Setting off

Steps for departing from land and raising the anchor.

Wireless remote control

How to use the wireless remote for anchor operations.

Anchor down

Instructions for lowering the anchor using the remote control.

Anchor up

Instructions for raising the anchor using the remote control.

Power indicator information

Explanation of the status lights on the remote control.

Forced operation of the windlass

Using the windlass for extended periods beyond auto-stop.

A brief description of the Engbo anchor system

Electronic control unit

Overview of the modern electronic components and their functions.

Switch panels

Standard touch panel

Details and installation of the standard watertight touch panel.

Wireless remote control

Information on available wireless remote models and their features.

Installation – general

Holder for wireless remote control

Instructions for mounting the holder for the wireless remote.

Hull conduit / Line guide

Guidance on installing a hull conduit for the rope.

Anchor rope

Information on the recommended Engbo anchor rope specifications.

Safety line

How to use the safety line to secure the anchor.

Auto stop

Explanation of the electronic auto stop function for anchor positioning.

Wireless remote

Fitting antenna

Steps to connect the aerial to the wireless remote's electronic unit.

Coding of the wireless remote control

Procedure for wireless remote controls with serial no. above 8600

Steps to code remote controls with specific serial numbers to the receiver.

Dimensional sketches

Maxi 31/40 – series

Diagrams and dimensions for Maxi 31 and 40 series windlasses.

Maxi 32 – series

Diagrams and dimensions for Maxi 32 series windlasses.

Maxi 33 – series

Diagrams and dimensions for Maxi 33 series windlasses.

Maxi 34-series

Diagrams and dimensions for Maxi 34 series windlasses.

Maxi 38-series

Diagrams and dimensions for Maxi 38 series windlasses.

Technical specifications

Electrical wiring

Switch panel

Details on connecting the standard touch panel switch.

Connecting the switch panel

Step-by-step guide for wiring the switch panel to the unit.

Connecting the auto stop switch

Wiring instructions for the auto stop switch.

Connecting the motor and battery cables

Guide for connecting motor and battery cables to the electronic unit.

Battery connection

Important warnings and procedures for connecting the battery.

Main power switch

Installation of the main power switch for safety.

Fuse and fuse holder

How to correctly install the fuse and fuse holder.

Electrical wiring diagram

Fitting instructions

General information

General guidelines for positioning and fitting the windlass.

Hinged platform roller

How to fit the anchor bracket with a hinged platform roller.

Line guide in the stern

How to check and fit the line guide in the stern opening.

Line guide

Using hull conduits with pulleys for guiding the rope.

The anchor bracket

Guidance on selecting and fitting different types of anchor brackets.

Fitting Maxi 31

Specific instructions for installing the Maxi 31 windlass.

Fitting Maxi 32

Specific instructions for installing the Maxi 32 windlass.

Maxi 32 box

Instructions for fitting the Maxi 32 line/chain box.

Fitting Maxi 33

Specific instructions for installing the Maxi 33 windlass.

Fitting Maxi 40

Specific instructions for installing the Maxi 40 windlass.

Fitting Maxi 34-V

Specific instructions for installing the Maxi 34-V windlass.

Fitting Maxi 34-D

Specific instructions for installing the Maxi 34-D windlass.

Fitting Maxi 34-G

Specific instructions for installing the Maxi 34-G windlass.

Drawing – Maxi 34-G – line wheel, rope guide, rope guard and fixing plate

Exploded view and parts list for Maxi 34-G assembly.

Fitting Maxi 34-S

Specific instructions for installing the Maxi 34-S windlass.

Fitting Maxi 34-H

Specific instructions for installing the Maxi 34-H windlass.

Fitting Maxi 38

Specific instructions for installing the Maxi 38 windlass.

Auto stop function

Adjust the auto stop switch

How to adjust the auto stop switch for correct operation.

Auto stop – fitting the stop indicator/brass wire

Steps to fit the brass wire indicators for the auto stop function.

Maintenance

Replacing the batteries in the wireless remote control

Guide to replacing batteries in the wireless remote control unit.

Replacing the line wheels

Instructions for replacing the line wheels of the windlass.

Line guide – adjusting the tension spring

How to adjust the tension spring of the line guide.

Winter storage

Recommendations for preparing and storing the windlass during winter.

Troubleshooting

Installation of equipment with high currents - special considerations

Preface/introduction

Introduction to special considerations for high current equipment installation.

General

General advice on high current equipment installation by knowledgeable persons.

Battery

Guidance on selecting and using batteries for high current equipment.

Battery-cables/lugs

Recommendations for choosing and mounting battery cables and lugs.

Battery connection

Correct procedures for connecting battery cables to terminals.

Fuse connection

How to correctly connect the fuse and fuse holder.

Main switch connection

Correct method for connecting the main power switch.

Control box connections

Tips and procedures for connecting cables to the control box.

Motor terminal connections

Instructions for connecting cables to the motor terminals.
