6 Maintenance
6.8.2. Significance of rotation play
Play of less than 0.12 mm will cause early overheating. Play greater than 0.25 mm will
have a leverage effect causing impact and shocks to destroy the lubrication film between
the thrust washers.
REMARKS
Lack of lubrication can deform the thrust washers.
6.8.3. ePS
If your tiltrotator is fitted with an engcon rotation sensor, it must be calibrated after
servicing.
6.9. Tightening torque
The rotator section is dimensioned to cope with major shear loads and torsional loads. For
reasons of strength, it is essential that certain fasteners be torque tightened.
Bolts and threaded holes must be thoroughly clean and the threads oiled.
EC204
Table 10.
EC206
Table 11.
47
