ECB3500
Wireless Long Range Multi-function 7+1 AP
2.4GHz Super G 108Mbps 7+1 Modes EIRP 2000mW
Bridge/Client Router/AP Router
Point-to-multipoint Wireless
connectivity
Let users transfer data between two buildings or multiple
buildings
WDS (Wireless Distributed System) Make wireless AP and Bridge mode simultaneously as a wireless
repeater
Repeater The easiest way to expand your wireless networking coverage
Support Multi-SSID function (4 SSID)
in AP mode (BSSID)
Allow clients to access different networks through a single access
point and assign different policies and functions for each SSID by
manager
Antenna diversity support Enhance the traffic signal
WPA2/WPA/ IEEE 802.1x support Powerful data security
MAC address filtering in AP mode(up
to 50)
Ensure the security of network connections
User isolation support (AP mode) Protect the private network between client users.
PPPoE function support (CR mode) Easy to access internet via ISP service authentication
Power-over-Ethernet (IEEE802.3af) Power supply via Ethernet cable which makes the setup more
flexible avoids restricting from wiring lines.
Technical Specifications
Hardware Specification
MCU Atheros AR2316, 180MHz
Memory 32MB SDRAM
Flash 8MB
Expansion Slots N/A
Physical Interface - LAN: One 10/100 Fast Ethernet RJ-45
- Reset Button
- Power Jack
LEDs Status - Power/ Status
- LAN (10/100Mbps)
- WLAN (Wireless Connection)
Power
Requirements
- Power Supply: 90 to 240 VDC ± 10％, 50/60 Hz (depends on different
countries)
- Active Ethernet (Power over Ethernet, IEEE802.3af)- 48 VDC/0.375A
