EnGenius ENS1750 - Physical Interface

10
Physical Interface
Dimensions and Weights
Length:280.48mm(11.22”)
Width:217.65mm(8.58”)
Depth:55.50mm(2.1”)
Weight:1.88Kg(4.17lbs)
1 LED Indicators: LED lights for Power, LAN Port 1, LAN Port 2,
2.4 GHz Connection and 5 GHz Connection.
2 LAN Port 1 (802.3at/48V PoE Input): Ethernet port for RJ-45
cable.
3 LAN Port 2: Ethernet port for RJ-45 cable.
4 Reset Button: Reset or Reboot the ENS Dual Band Access.
5 Mounting Holes: Using the provided screw set or pole mounting
ring, the ENS Dual Band series can be attached to a wall or pole.
1
32
4
5
