EnGenius ENS1750 - Mounting the ENS Dual Band Series

16
To attach the ENS Dual Band series to a wall:
1. Attach the location sticker to the desired location on
the wall and use a 6mm drill bit to drill the two marked
holes.
2. Insert the screw anchors into the 6mm holes drilled
then insert and the screws and tighten.
3. Align the access point over the keyhole mounting slots
and insert both screw heads into each keyhole slot. Then
slidetheaccesspointdownwarduntilit’srmlyhooked
in place.
2.
3.
1.
