EnGenius EnStation5-ACv2 User Manual

11
Physical Interface - ENS500-ACv2/ENS500EXT-ACv2
Dimensions
Length:186mm(7.32”)
Width:100(3.94”)
Depth:29mm(1.14”)
1 5 GHz Antennas Detachable 5 dBi 5 GHz Omni-directional
Antennas(ENS500EXT-ACv2Only)
2 LAN Port 1 (Proprietary24V PoE):EthernetportforRJ-45cable.
3 LAN Port 2 : Ethernet port for RJ-45 cable.
4 LED Indicators: LED lights for Power, LAN Port 1, LAN Port 2,
2.4 GHz Connection and 5 GHz Connection.
5 Mounting Holes: Using the provided hardware, the AP can be
attached to a wall or pole.
*Theinstallationangleofantennamustbeverticaltotheground.
4
1
23
1
5
