EnGenius EnStation5-ACv2 User Manual

10
Physical Interface-EnStation5-ACv2
Dimensions and Weights
EnStation5-ACv2
Dimension:190mm(7.48”)
Height:38mm(1.9”)
Weight:527g(1.16lbs)
1 WLAN Signal LED: Applied on Client Bridge/WDS
(1)Red:WeakSignal:Connectingqualityisbad.
(2)Yellow:ConnectingqualityisNormal.
(3)Green:ConnectionqualityisGood.
2 LAN(PoE) Signal LED
3 LAN Signal LED of the 2nd Port
4 Power Signal:
5 LAN Port 1:GigabitEthernetportforRJ-45cable.
6 LAN Port 2: Gigabit Ethernet port for RJ-45 cable.
5
4
1
6
2
3

EnGenius EnStation5-ACv2 Specifications

General

Brand	EnGenius
Model	EnStation5-ACv2
Category	Wireless Access Point
Language	English
