ENGIE EPS easyWallbox - Technical Specifications; Dynamic Power Management (DPM)

GB
GB
16
17
Housing Polycarbonate
Weight [kg] ~ 4
Standard Body colour Black (RAL 9011) and White (RAL 9010)
Status indication Y, led RGB
“335 x 277 x 95 (w/o Plug)
”
335 x 277 x 350 (with plug)
O verall body dimensions [mm]
General Specs
Enclosure ratings IP54, IK08 (IEC 60529)
Connectivity & Special Features
Bluetooth Y
Smartphone App My easyWallbox, compatible with Android, IOS
Service App easyWallbox Up! compatible with Android
Android version compatibility** Lollipop (5.0) or higher
IOS version compatibility** 12 or higher
Communication Protocol Proprietary
Dynamic Power Management Y, by installing the included sensor
** Data refer to the first release of the APP and may vary with future evolution
- Connection of the Dynamic Power Management sensor requires
installation by a professional.
- We recommend contacting qualified personnel or service for any
questions or doubts concerning easyWallbox’s use, installation,
and maintenance.
3.3. Technical features
Plug&Play Mode Power Upgrade Mode
3.4. Dynamic Power Management
easyWallbox includes Dynamic Power Management (DPM), a smart
function that modulates the charging power according to power
availability, thus avoiding unpleasant blackouts.
To activate the Dynamic Power Management, please see chapter 4.8 on
installation of the sensor.
easyWallbox can work even without Dynamic Power Management; in
this case, the installation of a dedicated sensor is not necessary, but
avoidance of blackouts is not ensured.
Electrical Specs and connection
Maximum Power [kW] up to 2.3* up to 7.4*
Voltage [V / Hz] 230 / 50, single-phase 230 / 50, single-phase
Current (Mode 2) [A] up to 10* up to 32*
Stand-by consumption [W] < 2 < 2
Cable with connector Type2 (EV side) Y, tethered included
Cable with connector Type2 Length [m] 3
Power Supply cable [m] 6 N.A.
* The values may vary in some countries according to local applicable standards
Safety and Operation
Temperature range [°C] -25 / +50 (without direct exposure to sunlight)
Overheating protection Y
Humidity Resistance Y, full coated
Class of Protection I
Pollution Degree PD3
Overvoltage category OVC III
Housing fire ratings UL94 V-0
Residual current monitoring Y, 6 mA DC sensitive RCM device included for DC-leakage detection
Maximum installation height [m] 2000 a.s.l.
281175 code
METER
CURRENT
SENSOR
MAIN SWITCHBOARD
Description
Connector Standard (EV side) IEC 62196-2
Power supply plug E/F (G in UK, J in Switzerland)
EVSE Standard IEC 61851
CE Mark Y
Warranty 2 years
Recharging Mode Mode 2 Mode 3, Mode 2 (France)
TÜV Certification Y Y
