Enotec ENSITU 7000 User Manual

Installation and Operation Manual - ENSITU
®
7000 System Description
Doc.-ID: ENS_13062019-EN 3
Figure 2 – ENSITU
®
7000 transmitter probe - electronics detached
Electronic unit - detached
Safe Area
Max. ambient temp.: -40 °C to +70 °C (-40 °F to +158 °F)
InSitu measuring probe
Safe Area
Max. ambient temp.: -40 °C to +80 °C (-40 °F to +176 °F)
Probe flange
Duct / combustion chamber
Counter flange (Optional)
Isolation Customer supply
Flue gas direction
Max. process gas temp: 600 °C (1112 °F)
Duct wall Manufacturer supply
Cable with plug. Max. cable
length + = 50 m
Customer supply
Power supply 48V DC, 5A max.
Optional: Power adapter from ENOTEC
Max. cable length + = 50 m
Input and output signals (analog and digital)
Test air / test gas in
