Enovation Controls MURPHY PowerCore TEC-10 User Manual

Software Release: [App: 02.09.10051.00; Config: 2.9.20024; Built in PowerVision Configuration Studio Version: 2.9.23042;
BTL: 02.09.10015.00]
Section 40 17 00-02-0939
2019-06-13
Quick-Start Setup
The following sections provide a walk-through of the steps necessary for some of the various configurations
and settings available on the MPC-10 / TEC-10 Controller. Cycling power to the controller is
recommended after making changes to set points.
Stepping through the Menu will be depicted as follows:
Menu/System/Contrast directs the operator to go into the Menu first, then look for a parameter titled System
and press [Enter] to go into the System menu. Then look for a parameter titled Contrast and press [Enter]
to go into the Contrast menu, etc.
Mechanical Engine Setup
1. Access Menu/Engine Settings/Engine Type, and select Mechanical then press [Enter].
2. Press down arrow to Engine Manufacturer, select which engine manufacturer the controller is/will be
used then press [Enter].
3. Press down arrow to Speed Source, and select either Alternator or Magnetic Pickup then press
[Enter].
4. Press down arrow to Speed Calibration, press [Enter].
5. Utilize the Up and Down arrows to establish the appropriate number of flywheel teeth or engine
alternator pulses, and press [Enter].
6. Press the [Back] key and down arrow to Throttle, and press [Enter].
7. Press [Enter] to access Manual Throttle Method, select throttle type if throttling the engine from the
controller for manually throttling the engine Inc/Dec, Run/Idle, Preset 3, or Preset 4 and press [Enter].
8. Press down arrow to Engine Throttle Type, select Pulse Inc/Dec or None and press [Enter].
9. Press down arrow to Target RPM Step Size, select appropriate step size then press [Enter].
10. Press down arrow to Throttle Deadband RPM, select appropriate deadband then press [Enter].
11. Press down arrow to Throttle Inc/Dec Pulse, select appropriate pulse time then press [Enter].
12. Press down arrow to Throttle Inc/Dec Pulse Delay, select appropriate pulse delay then press [Enter].
13. Press down arrow to Throttle Inc Rate, select appropriate throttle increment rate then press [Enter].
14. Press down arrow to Throttle Dec Rate, select appropriate throttle decrement rate then press [Enter].
15. Press the [Back] key, and down arrow to Input/Output, and press [Enter].
16. Access Analog Inputs and assign one Analog input for Oil Pressure and one for Engine Temperature.
Press [Enter] to save the settings.
17. Press [Back] and access Relay and Digital Outputs.
18. Press down arrow to Relay1-3 or DO1-4, and assign desired outputs for Crank, Fuel, and Inc/Dec
outputs if throttle type selected was Inc/Dec.
NOTE: DO3 and DO4 are factory set to Throttle Decrease and Throttle Increase to be
used with the Murphy AT03069 Throttle Actuator.
19. Press the [Back] key and up arrow to Advanced Engine Settings, and press [Enter].
20. Press down arrow to Warnings and Shutdowns, press [Enter].
21. Ensure all warnings and shutdowns are set to the appropriate settings for the engine for engine faults
such as oil pressure and coolant temperature.
22. Press the [Back] key twice and up arrow to System, and press [Enter].
23. Press down arrow to Set Machine Hours, select desired machine/internal hours then press [Enter].
24. Press the [Menu] key to exit the menu setup screens.
