Software Release: [App: 02.09.10051.00; Config: 2.9.20024; Built in PowerVision Configuration Studio Version: 2.9.23042;
BTL: 02.09.10015.00]
Section 40 43 00-02-0939
2019-06-13
Maintain Pressure (Medium Security): This selection is present when selecting Pressure Transducer
as the Auto Throttling Method. The engine will be throttled between the min. and max. RPM set
points to maintain this pressure. Factory set to 0 psi
Deadband Pressure (Medium Security): This selection is present when selecting Pressure
Transducer as the Auto Throttling Method. This extends above and below the maintain set point, no
throttling occurs while the pressure is in the deadband. Factory set to 0 psi
Pressure Type (Medium Security): Factory set to Discharge
Discharge: When the Auto Start/Stop is selected as Pressure Transducer and the Pressure Type
is set to (Discharge), it is necessary to set the pressure to start on a low value (falling ↓) then
stop on high value (rising ↑) in order to work correctly. When the Auto Throttle Method is selected
to Pressure Transducer and the Pressure Type is set to (Discharge), the controller throttles the
engine by increasing the RPM below the deadband and decreasing the RPM above the
deadband to maintain the desired level of Pressure.
Suction: When the Auto Start/Stop is selected as Pressure Transducer and the Pressure Type is
set to (Suction), it is necessary to set the pressure to start on a high value (rising ↑) then stop
on low value (falling ↓) in order to work correctly. When the Auto Throttle Method is selected to
Pressure Transducer and the Pressure Type is set to (Suction), the controller throttles the
engine by decreasing the RPM below the deadband and increasing the RPM above the
deadband to maintain the desired level of Pressure.
Line Fill 1 Speed (Medium Security): The engine is throttled to this speed after warm-up to purge the
line. Factory set to 900 RPM
Line Fill 1 Delay (Medium Security): This is the time the engine is held at the Line Fill 1 speed.
Factory set to 00.00.00
Line Fill 1 Pressure (Medium Security): The engine is held at the Line Fill 1 Speed until either this
pressure set point is reached or the Line Fill 1 Delay expires. Factory set to 0 psi
Line Fill 2 Speed (Medium Security): This selection is present when Hose Reel is selected in the
Applications menu. The engine is throttled to this speed after Line Fill 1 to fill the line. Factory set
to 900 RPM
Line Fill 2 Delay (Medium Security): This selection is present when Hose Reel is selected in the
Applications menu. This is the time the engine is held at the Line Fill 2 speed before advancing to
pressure throttle control. Factory set to 00.00.00
Line Fill 2 Pressure (Medium Security): This selection is present when Hose Reel is selected in the
Applications menu. The engine is held at the Line Fill 2 Speed until either this pressure set point is
reached or the Line Fill 2 Delay expires before advancing to pressure throttle control. Factory set
to 0 psi
Pressure P (High Security): This selection is present when PID Auto Throttle Type selected and allows
adjustment of the Proportional setting of the PID loop when throttling. Factory set to 0.020
Pressure I (High Security): This selection is present when PID Auto Throttle Type selected and allows
adjustment of the Integral setting of the PID loop when throttling. Factory set to 0.020
