Enovation Controls MURPHY PowerCore TEC-10 User Manual

Software Release: [App: 02.09.10051.00; Config: 2.9.20024; Built in PowerVision Configuration Studio Version: 2.9.23042;
BTL: 02.09.10015.00]
Section 40 56 00-02-0939
2019-06-13
5 = Check Safe to Start
6 = Prestart 2 Delay
7 = Crank
8 = Crank Rest
9 = False Start Check
10 = Engine Warmup
11 = Line Fill 1
12 = Line Fill 2
13 = Running Loaded
14 = Running Cooldown
15 = Energize to Stop
16 = Spindown
2 Bytes
24
39
Read Only
Controller State Timer
Seconds
FF96
1 Bit
16
16
Read & Write
Communication Engine Start/Stop Auto
Mode Only (Stop = 0, Start = 1)
(0 or 1)
FF97
1 Bit
16
16
Read & Write
Auto/Manual Mode
(Manual = 0, Auto = 1)
(0 or 1)
FF98
1 Bit
17
17
Read & Write
Manual Only
(Manual Only Active = 1,
Auto and Manual = 0)
(0 or 1)
FF99
1 Bit
18
18
Read & Write
Prestart 1 Auto Only
(Prestart Auto Only = 1,
Prestart Auto & Manual = 0)
(0 or 1)
FF9A
1 Bit
19
19
Read & Write
Prestart 2 Auto Only
(Prestart Auto Only = 1,
Prestart Auto & Manual = 0)
(0 or 1)
FF9B
2 Bytes
16
31
Read & Write
Running Loaded Speed in Auto Setpoint
RPM
FF9C
2 Bytes
16
31
Read Only
Active Discharge Pressure
kPa
FF9D
2 Bytes
16
31
Read & Write
Pressure Engine Start (Auto)
kPa
FF9E
2 Bytes
16
31
Read & Write
Pressure Engine Stop (Auto)
kPa
FF9F
2 Bytes
16
31
Read & Write
Pressure Maintain Value (Auto)
kPa
FFA0
1 Byte
16
23
Read & Write
Pressure Maintain Deadband (Auto)
kPa
FFA1
2 Bytes
16
31
Read Only
Actual System Level
Feet
FFA2
2 Bytes
16
31
Read & Write
System Level Engine Start (Auto)
Feet
FFA3
2 Bytes
16
31
Read & Write
System Level Engine Stop (Auto)
Feet
FFA4
2 Bytes
16
31
Read & Write
System Level Maintain Value (Auto)
Feet
FFA5
1 Byte
16
23
Read & Write
System Level Deadband (Auto)
Feet
FFA6
2 Bytes
16
31
Reserved
Reserved
Reserved
FFA7
2 Bytes
16
31
Reserved
Reserved
Reserved
FFA8
2 Bytes
16
31
Reserved
Reserved
Reserved
FFA9
2 Bytes
16
31
Reserved
Reserved
Reserved
FFAA
1 Byte
16
23
Reserved
Reserved
Reserved
FFAB
2 Bytes
16
31
Read Only
Actual Ambient Temp
Celsius
FFAC
2 Bytes
16
31
Read & Write
Ambient Temperature Engine Start (Auto)
Celsius
FFAD
2 Bytes
16
31
Read & Write
Ambient Temperature Engine Stop (Auto)
Celsius
FFAE
4 Bytes
16-48
Active Warning Status (Active Fault: Bit = 1, Inactive: Bit = 0)
16
16
Read Only
Low Fuel Warn
(0 or 1)
17
17
Read Only
Fuel Leak Warn
(0 or 1)
18
18
Read Only
Fuel Filter Restriction Warn
(0 or 1)
19
19
Read Only
Low Lube Level Warn
(0 or 1)
