Enovation Controls MURPHY PowerCore TEC-10 User Manual

Name: Enovation Controls MURPHY PowerCore TEC-10
Brand: Enovation Controls
Rating: 5 (1 reviews)

65 pages

To Previous Page

Software Release: [App: 02.09.10051.00; Config: 2.9.20024; Built in PowerVision Configuration Studio Version: 2.9.23042;

BTL: 02.09.10015.00]

Table of Contents5
Introduction7
Murphy Powercore 10 (MPC-10 / TEC-10)7
User Interface9
Accessing the Menu10
Main Menu11
Auto Start/Stop Functions Defined16
Single Contact Start/Stop (Commonly Known as Single Float in Pumping Markets)16
Two Contact Maintained Start/Stop (Commonly Known as Dual Floats in Pumping Markets)16
Pressure, Level and Temperature Transducer Start/Stop16
Local Start Key Start/Stop16
Quick-Start Setup17
Mechanical Engine Setup17
J1939 Electronic Engine Setup (Factory Default)18
Setting to Auto Start on a Single Contact Input (Single Float)18
Setting to Auto Start on Local Start Key19
Setting up to Auto Start/Stop for 2 Contact Inputs (Dual Floats)19
Setting to Auto Start on Pressure19
Setting up to Auto Start on Level20
Setting to Auto Start on Clock20
Setting to Auto Start on Temperature20
Setting up to Stop the Engine from Utilizing the Countdown Timer21
Screen Examples21
Additional Screens22
ISO Icons25
Icon Troubleshooting28
Menu Glossary28
System (Low Security)28
Engine Settings (Low Security)31
Advanced Engine Settings (Low Security)32
Throttle Menu (Medium Security)36
Input / Output Menu37
Application Configuration (Low Security)40
Start / Stop Timers (Low Security)46
Communication (High Security)48
Passcodes (High Security)49
Load Configuration (High Security) MPC-10 ONLY49
Communication Mapping50
This Section Outlines the RS485 Modbus Register Map and CAN Parameter Map50
MPC-10 & TEC-10 RS485 Modbus Registers50
CAN Parameter Map55
Supplementary Information59
Passcodes59
PC Configuration Software59
MPC-10 Specifications61
Interface61
Power Supply61
Inputs61
Outputs61
Communications61
Mating Connectors61
Physical / Environmental61
TEC-10 Specifications62
Interface62
Power Supply62
Inputs62
Outputs62
Communications62
Mating Connectors62
Physical / Environmental62
