00-02-0997 36 2016-06-15
Output 2
Follow these steps to change the Output 2:
1. Press to display the Menu.
2. Press to System Settings. Press to
enter.
3. Utilize keys 1, 2 and 3 to input the password (3482)
and key 5 to enter.
4. Arrow to highlight Output 2. Press to choose
Disabled, Comm Shdn or Air Shutoff.
Comm SHDN: When the Digital Output 2 is
configured as Comm SHDN, Digital Output 2
will turn ON for any CAN or internal diagnostic
shut-down message. Digital Output 2 will turn
back OFF when all the shut-down messages
are cleared.
Air Shutoff: The Digital Output 1 is disabled, the
Digital Output 2 is turned on, and an internal
Diagnostic Message (red lamp) is displayed
when the following conditions are met:
To Next Page
