Diagnostics and Service
LED Indicators
The PV380 features amber (Warning) and red (Shutdown)
colored LEDs on the front keypad. These are illuminated
according to the J1939 error definition for alarms and shut-
down conditions.
Indicator Lamps
On each gauge screen and menu (where space allows), the
following indicator lamps shall be shown:
