enphase IQ Envoy User Manual

IQ Envoy Installation and Operation
© 2017 Enphase Energy Inc. 141-00039 Rev 01
27
ED( If you used the Installer Toolkit scanning tool to scan microinverters, this screen displays the names
of the arrays and the number of microinverters associated with each array. Tap Connect to Envoy.
The Installer Toolkit automatically attempts to connect to the Envoy.
NOTE: If you used the Installer Toolkit scanning tool, the scanned microinverters are
provisioned on the Envoy when you tap Connect to Envoy. This action also stops the device
scan on the IQ Envoy, if one is in progress.
Refer to enphase.com/installer-toolkit/ for more information on the Enphase Installer Toolkit.

enphase IQ Envoy Specifications

General

Model	IQ Envoy
Category	Inverter
Enclosure Rating	NEMA 3R
Grid Connection	Single-phase
Warranty	5 years
Communication	Ethernet, Wi-Fi
Monitoring	Enphase Enlighten
Operating Temperature Range	-40°C to +65°C
