enphase IQ Envoy User Manual

IQ Envoy Installation and Operation
© 2017 Enphase Energy Inc. 141-00039 Rev 01
45
Internet Connection Options
Integrated Wi-Fi
802.11b/g/n (2.4 GHz, 5 GHz)
Ethernet
Optional, Ethernet cable [802.3, Cat5E (or Cat 6) unshielded twisted pair (UTP)].
Do not use shielded twisted pair (STP) cable.
Cellular
Optional, Enphase CELLMODEM-01 (3G) or CELLMODEM-03 (4G) (not included)
Measurement Circuit
Voltage
120 VAC or 120/240 VAC or 208Y/120 VAC at the power input terminal block
Current
Up to 200 A via CT inputs
Measurement Circuit
Per IEC/EN/CSA/UL 61010, CAT III
Metering options
• Model ENV-S-AM1-120: Revenue-grade production and consumption metering;
ANSI C12.20, 0.5 accuracy class.
• Model ENV-S-AB-120-A: Microinverter reporting; Accuracy +/- 5.0%
CSI Eligibility
The IQ Envoy is included in the List of Eligible System Performance Meters for the
CSI program.
Compliance
Compliance
UL 916,
CAN/CSA C22.2 No. 61010-1,
CAN ICES-003 (B)/NMB-003(B),
47 CFR, Part 15, Class B,
IEC/EN 61010-1:2010,
EN50065-1, EN61000-4-5, EN61000-6-1, and EN61000-6-2
Metering: ANSI C12.20 accuracy class 0.5 (ENV-S-AM1-120).
!

enphase IQ Envoy Specifications

General

Model	IQ Envoy
Category	Inverter
Enclosure Rating	NEMA 3R
Grid Connection	Single-phase
Warranty	5 years
Communication	Ethernet, Wi-Fi
Monitoring	Enphase Enlighten
Operating Temperature Range	-40°C to +65°C
