IQ System Controller 3M quick install guide IQ System Controller 3M quick install guide
Main lugs
Neutral terminals
Ground terminals
Load center for
DER breakers
AUX and System
Shutdown terminals
Terminals for
DER cables
Internal view of IQ System Controller 3M
The following gure shows the IQ System Controller 3M after the
dead front is removed. It comes with an inbuilt neutral forming
transformer, microgrid interconnection device, and a panel board to
mount plug-in type breakers.
Section B
Mounting the breakers
Hold-down kit
