IQ System Controller 3M quick install guide IQ System Controller 3M quick install guide
5. For sites with aggregate export power limit (PEL) enabled, indicate this with the label. Record the maximum operating kW value
on the label.
The label is provided as part of the IQ System Controller Literature kit.
AGGREGATE POWER EXPORT LIMIT LABEL:
ECO-007100: Initial Release.
HW
20MAY24
01
THE MAXIMUM POWER BACKFED BY THE SOLAR SYSTEM TO THE
UTILITY SERVICE MAY BE CONTROLLED ELECTRONICALLY. REFER
TO MANUFACTURER’S INSTRUCTIONS FOR MORE INFORMATION.
PCS CONTROLLED POWER SETTING: kW
125.00 +/- 0.3 mm
01
NOTES:
2. BACKGROUND COLOUR: WHITE, CONTENT COLOUR : REFER TABLE. VERIFY THE COLOUR WITH PANTONE SHADE CARD.
01
Colour Table - SEE NOTE 2
1. MATERIAL:
FOR ROLL FORM: USE 3M 7871 , MATERIAL THICKNESS: 0.051mm.
GLOSS RADIANT WHITE POLYESTER (0.051mm THICK) WITH #350 ACRYLIC ADHESIVE (0.046mm THICK)
AND 55# DENSIFIED KRAFT LINER (0.081mm THICK).
FOR SHEET FORM: USE 3M 7908 ,
MATERIAL THICKNESS: 0.051mm.
GLOSS RADIANT WHITE POLYESTER (0.051mm THICK)
WITH #350 ACRYLIC ADHESIVE (0.046mm THICK) AND 90# BLEACHED KRAFT SHEET (0.170mm THICK).
DATE OF CALCULATION AND SETTING:
30.0 +/- 0.3 mm
Recommended area to ax: On the dead front, below the transparent breaker, position the cover for the main breaker.
6. For sites with IQ Battery Oversubscription enabled, indicate this with the label.
Record the maximum operating current value on the label.
The label is provided as part of the IQ System Controller Literature kit.
IQ BATTERY OVERSUBSCRIPTION LABEL
LABEL, IQ BATTERY OVERSUBCRIPTION
FOR IQ SYSTEM CONTROLLER
01
780-01510
ECO-007100: Initial Release.
HW
19MAY24
01
150.00 +/- 0.3 mm
PCS CONTROLLED CURRENT SETTINGS FOR IQ BATTERY BREAKER: AMPS
PCS CONTROLLED CURRENT SETTINGS FOR DER BREAKER: AMPS
THE NAMEPLATE (CHARGE/DISCHARGE POWER) OF THE IQ BATTERY 5P
UNITS PROTECTED BY BREAKERS ON THIS PRODUCT ARE SET ELECTRONICALLY.
REFER TO MANUFACTURER’S INSTRUCTIONS FOR MORE INFORMATION.
19MAY24
19MAY24
Colour Pantone Colour Code
BRIGHT RED C
01
Colour Table - SEE NOTE 2
01
NOTES:
2. BACKGROUND COLOUR: WHITE, CONTENT COLOUR : REFER TABLE. VERIFY THE COLOUR WITH PANTONE SHADE CARD.
3. USE UV RESISTANT INK.
4. COMPLETED LABELS TO BE PACKAGED WITH PART NUMBER AND REVISION, MFG CODE AND DATE.
5. SUBMIT ALL ARTWORK SAMPLES WITH FAIR FOR APPROVAL.
6. LABEL MUST BE UL RECOGNIZED (PGDQ2) AND CSA ACCEPTED AS SUITABLE FOR OUTDOOR USE AT
TEMPERATURES FROM -40°C TO +65°C AND SUITABLE FOR THE SURFACE TO BE APPLIED (PER UL RECOGNIZED
COMPONENT DIRECTORY). EACH LABEL MUST BE MARKED WITH VENDOR’S MARK AS DEFINED IN THE CSA LIST OF
ACCEPTED ADHESIVE-TYPE NAMEPLATES. THE SMALLEST SHIPPING PACKAGE MUST BE MARKED WITH SUPPLIER’S
NAME AND UL DESIGNATION.
7. FINISHED PART MUST BE ROHS COMPLIANT (EU ROHS DIRECTIVE 2015/863/EU). MANUFACTURER WILL BE
REQUIRED TO CERTIFY ROHS COMPLIANCE. IF THERE IS A CONFLICT BETWEEN THE SPECIFICATIONS AND
ROHS COMPLIANCE, THE VENDOR MUST CONTACT ENPHASE FOR CLARIFICATION.
8. ALL DIMENSIONS ARE IN MILLIMETERS.
9. GENERAL TOLERANCE: +/- 0.3mm.
1. MATERIAL:
FOR SHEET FORM: USE 3M 7908 ,
MATERIAL THICKNESS: 0.051mm.
GLOSS RADIANT WHITE POLYESTER (0.051mm THICK)
WITH #350 ACRYLIC ADHESIVE (0.046mm THICK) AND 90# BLEACHED KRAFT SHEET (0.170mm THICK).
DATE OF CALCULATION AND SETTING:
Recommended area to ax: On the dead front, below the transparent breaker, position the cover for the main breaker.
7. For sites with PCS enabled, indicate with following label on the wired current transformers.
When using IQ Meter Collar, the label is already present on the product and need not be applied.
The label is provided as part of the IQ System Controller Literature kit.
CT LABEL
Recommended area to ax: On the CTs. When using the IQ Meter Collar for consumption metering, this label is already present
and need not be applied to the IQ Meter Collar.
8. Use the site congurations section in the Enphase Installer App to dene the PCS settings for the site.
Section D - Power Control System (PCS)
