23
Standard accessories 4-Series:
1498010 Device base (inclination support) (not for Vacotron 460)
3440001 Screwdriver
3444290 Power cord 250V/10A Europe-3x1 mm2 2.5 meter black
1498756 4-Series Information Booklet
1498757 4-Series Operating Instructions (cd rom)
Standard accessories ultrasound:
0167154 Information sheet ultrasound gel
0167314 Information sheet Mounting US Head Holder(s)
1498011 Holder for Ultrasound Head 4-Series - 1 for each ultrasound applicator
3442929
(1)
Contact-gel, bottle 250 ml, 1x
(1)
= The Sonopuls is delivered with 1 bottle of contact-gel. The article-number 3442929 however
represents a box of 12 bottles.
Standard accessories electrotherapy:
1460266 Moist pads for rubber electrodes 6x8 cm, set of 4 pcs.
3444020 Strap 100x3 cm
3444021 Strap 250x3 cm
2 x 3444129 Rubber electrodes 6x8 cm, 2 mm female, set of 2 pcs.
2 x 3444211 Patient cable 2-core & 2 mm male plugs - black, with coloured clips
Standard accessories vacuum:
2 x 3444503 Vacuum electrodes Ø 60 mm, set of 2 pcs.
3444505 Sponges Ø 65 mm, set of 4 (for vacuum electrodes Ø 60 mm)
2 x 3444507 Vacuum lead hose red
2 x 3444508 Vacuum lead hose black
6 Installation
6.1 Systems without a Vacotron
• Remove the 4-series device and any additional items ordered from the carton and inspect for
damage that may have occurred during shipment.
• Place the device on a desk or EN-Car. Ensure that there is sufficient air flow below the device (do
not place the device on a table-cover).
• If required, place the unit on the supplied inclination foot to improve display legibility
6.2 Systems with a Vacotron
• Remove the vacuum unit and any additional items ordered from the carton and inspect for
damage that may have occurred during shipment.
• Place the vacuum unit on a desk or EN-Car. Ensure that there is sufficient air flow below the
device (do not place the device on a table-cover)..
•
Remove the 4-series device and any additional items ordered from the carton and inspect for
damage that may have occurred during shipment.
• Place the main device on top of the vacuum unit.
• Carefully lift the main device at the front and insert flat cable [17] into connector [18].
6.3 Connection to mains supply
• Insert the mains cable into socket [1] and connect it to a wall socket.
