31
To adjust the output amplitude of a channel, touch the tab of the selected channel again. Its colour will
change into orange. The output amplitude can now be adjusted with the central controller [7].
For some applications, such as interferential therapy and combination therapy, two adjacent channels can
be linked. Linked channels are indicated by a combined tab. The tab halves show the output amplitude of
each channel, while the parameters on the remainder of the sheet apply to both channels.
When you turn on the unit, you will first enter the Home menu. In the Home menu none of the channels
are selected. The Home menu provides a structured access to all therapies available within the unit, with
appropriate parameter defaults. Just select a menu item by touching the button to navigate to the next
screen. You can navigate back to the previous screen by touching the back arrow at the top of the
screen. Anywhere in the navigation, you can jump back to the Home menu, by touching the home button.
8.2.3 Navigation
8.2.3.1 Electrotherapy
Home
The Home menu gives access to all functions of the unit. Select the
desired function or therapy by touching the button
The next screen appears
Electrotherapy “Clinical Protocols”
The electrotherapy menu gives access to functions
• Clinical Protocols
• Favorites
• Manual Operation
• Programming
Select Clinical Protocols by touching the button
The next screen appears
Use the central controller to scroll through the list and select the
clinical protocol by touching the button.
The channel selection screen appears.
For therapy information touch the info button on the left side of the
protocol and the therapy info will appear.
