Enraf Nonius Sonopuls 490 Operating Instructions

53
The 4-series device is intended for operation in an electromagnetic environment where RF disturbances
are monitored. The customer or user of the 4-series device can help prevent electromagnetic
interference by maintaining a minimum distance between portable and mobile RF telecommunications 4-
series (transmitters) and the 4-series device – according to the output power of the communications
device, as indicated below.
Rated output of transmitte
r
W
Separation distance according to frequency of transmitte
r
m
150 kHz to 80 MHz
d= 1.2 √P
80 MHz to 800 MHz
d= 0.35 √P
800 MHz to 2.5 GHz
d= 0.7 √P
0.01 0.12 0.035 0.07
0.1 0.38 0.11 0.22
1 1.2 0.35 0.70
10 3.8 1.1 2.2
100 12 3.5 7
For transmitters rated at a maximum output which is not listed above, the recommended separation distance d in
meters (m) can be determined using the equation applicable to the respective column, whereby P is the maximum
rated output of the transmitter in Watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz the higher frequency range is applicable.
NOTE 2 These guidelines may not be applicable in all cases. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
11 Ordering information
Model numbers:
1498901 Sonopuls 490 with large ultrasound applicator
1498902 Sonopuls 490 with small ultrasound applicator
1498903 Sonopuls 490 with large and small ultrasound applicator
1498911 Sonopuls 492 with large ultrasound applicator
1498912 Sonopuls 492 with small ultrasound applicator
1498913 Sonopuls 492 with large and small ultrasound applicator
1498920 Endomed 482
1498950 Vacotron 460
Standard accessories Sonopuls 492:
1498757 4-Series Operating Instructions (cd rom)
1498756 4-Series Information Booklet
3444290 Mains cable 230V-EUR
1498010 Device base (inclination support) (not for Vacotron 460)
xxxxxxx Ultrasound multi-frequency treatment head(s) (model dependent)
xxxxxxx Holder treatment head (model dependent)
3442929
(1)
Contact-gel, bottle 250 ml, 1x
3444021 Strap 250x3 cm
3444020 Strap 100x3 cm
2 x 3444129 Rubber electrodes 6x8 cm, 2 mm female, set of 2 pcs.
1460266 Moist pads for rubber electrodes 6x8 cm, set of 4 pcs.
2 x 3444211 Patient cable 2-core & 2 mm male plugs - black, with coloured clips
(1)
= The Sonopuls is delivered with 1 bottle of contact-gel. The article-
number 3442929 however represents a box of 12 bottles.
