29
!CAUTION:
• The supply current of this connection is limited to 100 mA. Do not connect USB mass storage
devices such as USB powered hard disks, as this might result in data loss. Only USB-sticks are
allowed.
[4] On/Off push button:
This button is used to turn the device On or Off
[5] Power LED indicator:
Green: Device connected to mains supply. When a battery is present, it is charged.
Orange: Device operating from battery
[6] Display with Touch screen technology:
[7] Central controller with light ring
Use this controller to scroll through the pages and to adjust the parameters. The light ring is illuminated
when the controller is ready to use.
[8] Connection Electrode Cable Electrotherapy channel 1
[9] Connection Electrode Cable Electrotherapy channel 2
[10] Connection Ultrasound applicator A
[11] Connection Ultrasound applicator B
!CAUTION:
• Connection of accessories other than the ones specified by the manufacturer can adversely
affect the safety of the patient and correct functioning of the equipment, and is therefore not
permitted. For combined applications only use Enraf-Nonius type BF equipment. The very low
leakage current of this type of equipment ensures absolute safe therapy.
• The ultrasound applicator is a precision instrument. Great care has been taken during the
development and in production to obtain the best possible beam characteristics. Rough treatment
(jarring or dropping) can adversely affect these characteristics, and must therefore be avoided.
[12] Connections Vacuum Cables Electrotherapy channel 1
[13] Connections Vacuum Cables Electrotherapy channel 2
[14] Interconnection cable vacuum unit to main unit
[15] Upper hose nipple
!CAUTION:
Connections [8] [9] [10] [11] [12] [13] are intended for the connection of type BF applied parts
complying with the leakage current requirements of IEC 60601-1.
