NOWPAK LINER-BASED CANISTER SYSTEM
User Manual | Entegris, Inc.
APPENDIX B: CANISTER COMPATIBILITY MATRIX
—
The following table provides a quick method of checking which components can be used with each of the
liner-based canister sizes (4- to 200-liter).
Not all possible configurations are shown. Contact Entegris for additional configuration options.
IMPORTANT: The user must ensure that the selected liner is properly sized for the canister being used. Entegris does not
recommend using any diptube or liner designed or provided by anyone other than Entegris.
Capacity Canister Liner Closure
Closure
O-ring type Diptube
Diptube
O-ring type
Dispense
connector
4-liters NO-04 NL-004-T420A-1
NL-004-N500C-1-KA
NC-03
NC-03-2
EPDM
FEP-
encapsulated
silicone
NDT-T4
NDT-T4-C
EPDM
Chemraz
ND-CD-SXXX-XXX
4-liters NO-04-63 NL-004-T420A-1
NL-004-N500C-1-KA
NC-04
NC-04-2
EPDM
FEP-
encapsulated
silicone
NDT-T4
NDT-T4-C
EPDM
Chemraz
ND-CD-SXXX-XXX
10-liters NO-05 NL-010-T420A-1
NL-010-N500C-1-KA
NC-03
NC-03-2
EPDM
FEP-
encapsulated
silicone
NDT-T5
NDT-T5-C
EPDM
Chemraz
ND-CD-SXXX-XXX
ND-ED-S-2
(MaxMT)
10-liters NO-05-63 NL-010-T420A-1
NL-010-N500C-1-KA
NC-04
NC-04-2
EPDM
FEP-
encapsulated
silicone
NDT-T5
NDT-T5-C
EPDM
Chemraz
ND-CD-SXXX-XXX
ND-ED-S-2
(MaxMT)
18-liters NO-09 NL-018-T420A-1
NL-018-T650A-1
NL-018-N500C-1-KA
NC-03
NC-03-2
EPDM
FEP-
encapsulated
silicone
NDT-T9 EPDM ND-CD-SXXX-XXX
ND-ED-S-2
(MaxMT)
18-liters NO-09-63 NL-018-T420A-1
NL-018-T650A-1
NL-018-N500C-1-KA
NC-04
NC-04-2
EPDM
FEP-
encapsulated
silicone
NDT-T9 EPDM ND-CD-SXXX-XXX
ND-ED-S-2
(MaxMT)
19-liters NO-08 NL-020-T420A-1
NL-020-T650A-1
NL-019-N500A-1-KA
NL-019-N500C-1-KA
NL-019-N500D-1-KA
NL-019-NS50C-1
NL-019-NS50A-1
NC-03
NC-03-2
EPDM
FEP-
encapsulated
silicone
NDT-T8
NDT-T8-C
NDT-P8
NDT-P8-C
NDT-P8-F
EPDM
Chemraz
EPDM
Chemraz
Semi-
perfluoro-
elastomer
ND-CD-SXXX-XXX
ND-ED-S-2
(MaxMT)
