Redundant Power Supply Specifications
A-4 Specifications
STK-RPS-150CH8 Chassis Specifications
Table A-3 provides the physical specifications for the STK-RPS-150CH8.
STK-RPS-150PS Specifications
Table A-4 provides the specifications for the STK-RPS-150PS.
Table A-3 STK-RPS-150CH8 Specifications
Item Specification
Power supply slots Eight slots for optional STK-RPS-150PS power supplies
Dimensions without mounting brackets 22.26 H x 44.0 W x 26.4 D (cm)
8.77 H x 17.3 W x 10.4 D (in.)
Net Weight (Unit Only)
Gross Weight (Packaged Unit)
5.27 kg (11.6 lb)
6.5 kg (14.3 lb)
Table A-4 STK-RPS-150PS Specifications
Item Specification
Electrical
AC Input Frequency Range
AC Input Voltage Range
Output Voltage
Output Current
Maximum Output Power
47–63 Hz
85–264 Vac
12 Vdc
1.0 A min., 8.5 A or 13.0 A max.
102 W or 156 W continuous
Physical
Dimensions 19.6 H x 5.2 W x 25.7 D (cm)
7.7 H x 2.04 W x 10.1 D (in.)
Net Weight (Unit Only)
Gross Weight (Packaged Unit)
1.75 kg (3.85 lb)
3.20 kg (7.04 lb)
MTBF 300,000 Hours
